KARATINTL Barcodescanner_
KARATINTL 1532 2D CMOS Handheld Wire Barcode Scanner
| Interface | USB HID KEYBOARD/USB VCP |
| Voltage requirement |
DC 5V±10% |
| Current consumption |
Max:120mA |
| Light source |
White LED*1 |
| AIM light source | Red Bar LED |
| Photo sensor | CMOS arraay sensor |
| Sensor Resolution |
648×488 pixels |
| Decode angle | Pitch angle: ±55° Skew angle: ±55° Tilt angle: ±180° |
| Min resolution | 1D:5mil( 0.127mm) |
| Min .PCS value | >30%UPC/EAN 13(13mil) |
| Field of View | 20°(H), 21° (V) |
| Compatibility | Win OS / Mac OS/ Linux Android/IOS/Embedded OS |
| Mechanical shock |
1.2m drop onto concrete surface |
| Temp | -20° to 60°C / -4° to 140°F(operation) -40° to 80°C /-40° to176°F(storage) |
| Humidity | 5 - 95% (operation) 5 - 95% (storage) |
| Ambient Light | Fluorescent light: 4000 lx max Direct sun light: 80,000 lx max White light: 4000 lx max |
| Decode capability |
1D : UPC/EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI 2D : QR |
| Environmental | RoHS |
| Dimensions | 97mm x 67mm x 165mm(L*W*H) |
| Weight | 122.8g |
